Silicone Flat Caps – SFC

Flach- Kappen aus Silikon ( FSC-Serie )    / Silicone Flat Caps

  • Reduces Creepage in Applications Where Temperatures Change Rapidly
  • Flexible Enough to Conform to Irregular Geometry
  • Flat Top Aids Insertion and Minimizes any Air Trap
  • Flat Silicone Caps are Reusable, and Will Not Melt or Harden



Product Description:

Used as a cap over threaded studs, dowels, and protrusions. Our Silicone Flat  Cap (SFC) product line is an alternative to our Silicone Cap (SC) product line for capping applications. Their versatile nature allows them to fit over extrusions, threaded studs, PEMS and dowels. Our high temperature Silicone is specially formulated to ensure reusability and economy during masking.

Helpful Hints:

  • Alternate to many Silicone Cap (SC) sizes.
  • When sizing parts as a cap, the ID of the cap should be 2 – 5% smaller than the stud diameter.



ZG-FC-Kappen

All Dimension in mm

Get a sample or offer

Part No. Metric ID Length Wall PCS/BAG
SFC-0070-1000 1,78 25,4 1,52 1000
SFC-0100-1000 M3 2,54 25,4 1,52 1000
SFC-0100-1120 M3 2,54 28,45 1,52 1000
SFC-0120-0400 3,05 10,16 1,52 1000
SFC-0120-1000 3,05 25,4 1,52 1000
SFC-0145-1120 3,68 28,45 1,52 1000
SFC-0148-1000 M4 3,76 25,4 1,52 1000
SFC-0172-0800 M5 4,37 20,32 1,52 1000
SFC-0175-1000 4,45 25,4 1,52 1000
SFC-0185-1120 4,7 28,45 1,52 1000
SFC-0220-1120 5,59 28,45 1,52 1000
SFC-0220-1650 5,59 41,91 1,52 1000
SFC-0223-1500 M6 5,66 38,1 1,52 1000
SFC-0234-1500 1/4" 5,94 38,1 1,52 1000
SFC-0295-0250 M8-5/16" 7,49 6,35 1,52 1000
SFC-0295-1500 M8-5/16" 7,49 38,1 1,52 500
SFC-0300-1120 7,62 28,45 1,52 500
SFC-0300-1650 7,62 41,91 1,52 500
SFC-0355-1500 9,02 38,1 1,52 500
SFC-0375-1120 M10 9,53 28,45 1,52 500
SFC-0375-1500 M10 9,53 38,1 1,52 500
SFC-0393-0728 9,98 18,49 1,52 500
SFC-0415-1500 10,54 38,1 1,52 500
SFC-0437-1000 11,1 25,4 1,52 500
SFC-0440-0728 11,18 18,49 1,52 500
SFC-0456-1120 M12 11,58 28,45 1,52 500
SFC-0456-1500 M12 11,58 38,1 1,52 500
SFC-0480-1500 1/2" 12,19 38,1 1,52 500
SFC-0535-1500 M14 13,59 38,1 1,52 500
SFC-0562-1500 M16 14,27 38,1 1,52 500
SFC-0590-0708 14,99 17,98 1,52 500
SFC-0600-1500 15,24 38,1 1,52 250
SFC-0640-0900 16,26 22,86 1,52 250
SFC-0640-2000 16,26 50,8 1,52 250
SFC-0665-0732 16,89 18,59 1,52 250
SFC-0687-0330 M18 17,45 8,38 1,52 250
SFC-0722-4555 18,34 115,7 1,52 100
SFC-0728-0452 3/4" 18,49 11,48 1,52 250
SFC-0730-1500 3/4" 18,54 38,1 1,52 250
SFC-0730-4000 3/4" 18,54 101,6 1,52 100
SFC-0736-0728 M20 18,69 18,49 1,52 250
SFC-0811-0728 M22-7/8" 20,6 18,49 1,52 250
SFC-0855-1500 21,72 38,1 1,52 250
SFC-0921-0728 23,39 18,49 1,52 250
SFC-0970-4000 M25-1" 24,64 101,6 1,52 100
SFC-0980-1500 24,89 38,1 1,52 250
SFC-1000-0650 M27 25,4 16,51 1,52 250
SFC-1220-0670 30,99 17,02 1,52 250
SFC-1291-0905 32,79 22,99 1,52 100
SFC-1555-1102 39,5 27,99 1,52 100
SFC-1575-0670 40,01 17,02 1,52 100
SFC-1649-1102 41,88 27,99 1,52 100
SFC-1772-0670 45,01 17,02 1,52 100
SFC-1850-1102 46,99 27,99 1,52 100
SFC-1957-1515 49,71 38,48 1,52 100
SFC-2248-1023 57,1 25,98 1,52 100
SFC-2885-1000 73,28 25,4 1,52 50
